Lifebreath RNC Series RNC4-TPD HRV (Compact)

$1,448.00 CAD

Our smallest unit to date. Ideal for small homes and townhomes with tight space requirements. Features a top port design, door port balancing, 4″ duct connections, and our patented high-efficiency core.

THERMALLY CONDUCTIVE, PATENTED ALUMINUM CORE The counter-flow heat recovery core transfers heat between the two airstreams. It is easily removed for cleaning or service.
MOTORS AND BLOWERS Each airstream has an independent motorized impeller with multiple fan speed operations.
FILTERS Washable air filters in exhaust and supply airstreams.
MOUNTING Four threaded inserts at corners of the cabinet designed to accept the “S” hooks and hanging straps supplied with the unit.
DEFROST Recirculating damper defrost system.
INSTALLER SELECTABLE HIGH SPEED SETTINGS Adjustable DIP switches are located on the circuit board, Hi3 is the factory setting. Refer to the Installation manual for the adjustment instructions. ELECTRONICS The optional control can be wall mounted in a central location of the home. 3 wire 20 gauge (min.) 100 ft length (max.).

Refresh Air

Block Pollutants

Recover Heat & Cold

Any Questions? Call 1-888-727-4320 or Send a Message Online

Fast Shipping to Canada & U.S. (Shipping Policy)

Local Pickup (Ottawa Store - K2E 7M3)

Secure Checkout via Paypal

Lifebreath RNC4-TPD Residential Heat Recovery Ventilator HRV

THERMALLY CONDUCTIVE, PATENTED ALUMINUM CORE The counter-flow heat recovery core transfers heat between the two airstreams. It is easily removed for cleaning or service.
MOTORS AND BLOWERS Each airstream has an independent motorized impeller with multiple fan speed operations.
FILTERS Washable air filters in exhaust and supply airstreams.
MOUNTING Four threaded inserts at corners of the cabinet designed to accept the “S” hooks and hanging straps supplied with the unit.
DEFROST Recirculating damper defrost system.
INSTALLER SELECTABLE HIGH SPEED SETTINGS Adjustable DIP switches are located on the circuit board, Hi3 is the factory setting. Refer to the Installation manual for the adjustment instructions. ELECTRONICS The optional control can be wall mounted in a central location of the home. 3 wire 20 gauge (min.) 100 ft length (max.).

Warranty: Units carry a lifetime warranty on the HRV core and a 5 year replacement parts warranty.

- Manufacturer: Airia Brands
- Series: Lifebreath RNC Series
- Model Description: RNC4-TPD
- Ventilation Performance: 58 cfm @0.4 in. wg
- Manufacturer’s Part Number: 43916
- Wall Controller Included: none
- Core Type: Heat Recovery Ventilator (HRV)
- Heat Recovery Rate: 70%
- Moisture Transfer rate: 0%
- Core Material: Aluminum
- Core Filters: (Qty. 2) washable foam filters
- Defrost Type: Damper Defrost / Recirculating (spoiled air = 4 ports)
- Port Location: Vertical
- Port Sizes: 4 inch
- Motor Type: PSC
- Power Consumption (Low Speed): 38 watts
- Balancing Method (if required): please see below
- Air Flow Measured Via: integrated pressure door taps
- Air Flow Adjusted Via: integrated balancing dampers
- Unit Dimensions: Ht: 19.25″ / W: 18″ / D: 19″
- Unit Weight: 35 lbs / 16 kg
- Parts Warranty: 5 Years
- Core Warranty: Lifetime limited
