The BalancedHome® Elite Plus Energy Recovery Ventilator (ERV) keeps your home fresh and comfortable by bringing in fresh air while exhausting stale air. Independent supply and exhaust settings ranging from 30 to 130 CFM provide balanced ventilation while recovering energy from the exchanged air. Add an optional manual boost switch/timer to achieve up to 130 CFM on demand. This ERV is engineered for use in any temperate North American climate zone.

• ENERGY STAR® Certified
• Side Port: FV-13VEC1S / Top Port: FV-13VEC1T
• Two Panasonic frost prevention strategies (Recirculation and Exhaust Only modes)
• Max fan speed of 130 CFM
• Smart Flow® technology ensures consistent airflow
• SRE up to 82% (FV-13VEC1S, FV-13VEC1T) complies with IECC code requirements
• Two (2) DC-enclosed ECM brushless motors rated for continuous run
• Power rating 120V/60hz, 3.1 amps
• Built-in Frost Prevention Mode helps prevent the core from freezing.
• Four integrated 6” duct adaptors (2 exhaust, 2 supply)
• MERV 13 filter (FV-FL1316VE1) included
• Replacement MERV 8 (FV-FL0815VE1) and washable MERV 6 (FV-FL0616VE1) available

• Panasonic’s hygroscopic core balances humidity between indoor/outdoor airflows
• Filter maintenance indicator on the ERV notifies the user when filter maintenance is required

• All models are equipped with a standard power cord and include a hardwire conversion kit
• Wall Control/Fault Indicator Display (FID) FV-SCVE2 (sold separately).

Warranty: 6 years on ECM motors and 3 years on all other parts from the original purchase date

Documents:
Installation & Operating Manual - ERV - BalancedHome® Series
Spec Sheet - ERV - BalancedHome® - FV-13VEC1S
Spec Sheet - ERV - BalancedHome® - FV-13VEC1T
