Clean Comfort Electronic Air Cleaner Replacement Media Pad Replacement Pads for AE10 SERIES OF HYBRID AIR CLEANERS Features • High efficiency filtration – Up to 95% removal of particulates down to 3 microns • Low energy consumption – unit consumes less than 2 Watts when operating • Easy and cost-effective to maintain • Wide range of standard and custom sizes to fit all 1" furnace or air handler filter racks Specifications Electrical: Nominal Voltage Required 24 VAC Current Draw 0.1 Amp maximum at 24 VAC Power Consumption 2 Watts maximum Voltage Range 22 to 30 VAC Static Pressure Drop 0.15" – 0.17" w.c. Dimensions Various (see table below) Example of Air Cleaner Area Calculation: Height of air cleaner frame (inches) 16 inches Width of air cleaner frame (inches) 25 inches Area of air cleaner frame            (square inches) 400 square inches Divide area by 144 to get area in square feet                        2.8 square feet This air cleaner would be suitable for any system where the recommended minimum filter size is                                     2.8 square feet or less

Replacement Filter Pads  Note: Each package of replacement pads contains 6 pieces.   Use two pieces each time the pads are changed. It is recommended that the pads be replaced  every three to four months, based on conditions within the home.
Description	Air Cleaner Part #	Replacement Pad Part #
1” Electronic Air Clnr 12X24	AE10-1224-14	AEP-GA1-1224
1” Electronic Air Clnr 13X21.5	AE10-1321-14	AEP-GA1-1321
1” Electronic Air Clnr 14X20	AE10-1420-14	AEP-GA1-1420
1” Electronic Air Clnr 14X24	AE10-1424-14	AEP-GA1-1424
1” Electronic Air Clnr 14X25	AE10-1425-14	AEP-GA1-1425
1” Electronic Air Clnr 14X30	AE10-1430-14	AEP-GA1-1430
1” Electronic Air Clnr 15X20	AE10-1520-14	AEP-GA1-1520
1” Electronic Air Clnr 16X20	AE10-1620-14	AEP-GA1-1620
1” Electronic Air Clnr 16⅜X21.5	AE10-1621-14	AEP-GA1-1621
1” Electronic Air Clnr 16X24	AE10-1624-14	AEP-GA1-1624
1” Electronic Air Clnr 16X25	AE10-1625-14	AEP-GA1-1625
1” Electronic Air Clnr 18X20	AE10-1820-14	AEP-GA1-1820
1” Electronic Air Clnr 19.5X20	AE10-1920-14	AEP-GA1-1920
1” Electronic Air Clnr 20X20	AE10-2020-14	AEP-GA1-2020
1” Electronic Air Clnr 19⅞X21.5	AE10-2021-14	AEP-GA1-2021
1” Electronic Air Clnr 20X24	AE10-2024-14	AEP-GA1-2024
1” Electronic Air Clnr 20X25	AE10-2025-14	AEP-GA1-2025
1” Electronic Air Clnr 20X30	AE10-2030-14	AEP-GA1-2030
1” Electronic Air Clnr 20X36	AE10-2036-14	AEP-GA1-2036
1” Electronic Air Clnr 21.5X23-5/16	AE10-2123-14	AEP-GA1-2123
1” Electronic Air Clnr 24X24	AE10-2424-14	AEP-GA1-2424
1” Electronic Air Clnr 23X20	AE10-2320-14	AEP-GA1-2320
