Clean Comfort Heat Recovery Ventilator VH70220

A heat recovery ventilator (HRV) like the VH70220 will remove stale air from your home and replace it with fresh indoor air. While doing so, it will also capture close to 70% of the excess heat in the exhaust air and use it to preheat the incoming air. The VH70220 will supply fresh air to your home year round, while also minimizing the additional load on your heating and cooling equipment.

Clean Comfort HRV Features:

  • Airflow Rates 70 CFM (33 L/s) to 220 CFM (104 L/s)
  • Motors: Two PSC variable-speed backward curved. Maximum RPM 2695; 3/32 HP, Class F, thermally protected
  • Voltage: 120 VAC @ 60 Hz / 1 Phase
  • Amperage: 1.5 A / 142 W
  • Three operating modes (Intermittent, Continuous and High)
  • 100% variable speed
  • Integrated door pressure balancing taps
  • Defrost type Evacuation: activated automatically at 23°F (-5°C)
  • ISF™ (Insert, Slide and Fix) 6" (153 mm) dia. collar system
  • Advanced proportional supply fan shut-down defrost sequence
  • Dual permanently lubricated PSC motors
  • Integrated auxiliary furnace interlock relay
  • Ventilator can be balanced by adjusting each motor independently; no balancing dampers required
  • Connection terminals for optional wall controls
  • Adjustable hanging chains included
  • Includes the VHP-RD2 wall control
  • Quiet operation

Optional Wall Controls:
Mechanical VHP-RD1, VHP-TC10 or VHP-DC15
Timers VHP-T3 (20, 40, 60 minutes)


Air Quality Protection Clean Comfort Recovery Ventilators take care of the air you breathe by going beyond heating and cooling, removing odors and ensuring pollution-free comfort and exceptional indoor air quality.
Advanced Defrost Operation Clean Comfort's VH70220 supplies your home with fresh outdoor air even while preventing freezing by gradually adjusting intake fan speed. Control Flexibility The VH70220 features a number of optional controls to select from that offer a variety of operating modes too allow you to make system-specific adjustments.
Dual-Motor Defense Clean Comfort's independently controlled dual motors allow for easy balancing with air dampers, providing increased precision and optimal home pressurization.
Easy Ducting Connections Clean Comfort recovery ventilators feature an exclusive ISF (Insert, Slide and Fix) collar system that makes installation and maintenance easier than other manufacturers' devices.
