The VE30160 energy recovery ventilator (ERV) provides a continuous supply of fresh air while exhausting stale indoor air to improve indoor air quality. Its enthalpic core transfers both heat and moisture between incoming and outgoing air streams, helping maintain indoor comfort and reduce energy costs year-round. Equipped with variable-speed motors and an automatic defrost system, it delivers efficient and reliable ventilation in all seasons.

Features
• Two PSC variable-speed motors with backward-curved blades
• Cross-flow enthalpic polymer membrane heat exchanger
• Molded expanded polystyrene (EPS) corrosion-resistant liner
• Automatic defrost system (activated at 23°F / -5°C)
• Four 6" duct connections with ISF double collar system
• Washable Fiberbond filters
• Compact steel cabinet construction

Optional Controls
• VHP-RD1 dehumidistat
• VHP-TC10 controller
• VHP-DC15 control
• VHP-T3 timer (20/40/60 minutes)

Specifications
• Cabinet dimensions: 29½" x 22½" x 11⅜" (749.3 mm x 571.5 mm x 289 mm)
• Duct size: 6" (152.5 mm) diameter (4 ports)
• Voltage/Phase: 120 VAC / 1 Phase / 60 Hz
• Power rating: 142 W
• Current: 1.5 A
• Airflow range: 30 to 160 CFM (14 to 76 L/s)
• Motors: 2 PSC, max 2695 RPM, 3/32 HP, Class F, thermally protected
• Heat exchanger: cross-flow enthalpic core, 85 ft² (7.9 m²) surface
• Heat exchanger dimensions: 12" x 12" x 10" (304.8 x 304.8 x 254 mm)
• Defrost type: evacuation, auto at 23°F (-5°C)
• Filters: 2 washable Fiberbond, 11-11/16" x 9-3/4" x 5/8"
• Drain connection: ½" (12.7 mm)
• Weight: 42 lbs (19 kg)
• Shipping weight: 47.5 lbs (21.5 kg)
