FANTECH MOST COMPACT MODEL VHR70R ES HRV

Model NO.:  VHR70R ES, Fantech. VHR70R ES is a compact HRV specially designed for small residential and multi-residential applications such as condominiums and apartment buildings that require up to 70 CFM continuous principal ventilation. With its flexible and compact top port design incorporating the 5" oval collars with integrated airflow measurement and EZ-Mount™ wall bracket, it can be installed in small spaces such as 24" closets or above the hot water heater. RESIDENTIAL USE ONLY Features • 5" (125mm) oval duct connections with integrated airflow measurement • Removable screw terminal for easy connection • Lightweight: only 32 lbs (14.5 kg) including core • Super compact size • Top port design fits in tight spaces • Includes EZ-Mount wall bracket • Aluminum heat recovery core • Multiple speed operation • Internal recirculation defrost Optional Controls: • Eco-Touch™ (#44929) – Programmable Touch Screen Wall Control • EDF7 (#44883) – Electronic multi-function dehumidistat • EDF1R (#40393) – Multi-function control • RTS2 (#40164) – 20 minute timer over-ride • RTS5 (#44794) – 20/40/60 minute timer • MDEH1 (#40172) – Dehumidistat Specifications • Duct size – 5" (125 mm) oval • Voltage/Phase – 120/1 • Power rated – 60 W • Amperage – 1.1 A • Average airflow – 70 cfm (33 L/s) @ 0.4" Ps (100Pa)
