Bilsom® Prestige® Programmable Thermostat Low Voltage, 32 - 120 deg F Contact, +/- 1 deg F Differential, 3 Conventional, 4 Heat Pump, 2, 4, 7, R, RC, RH, C, W-O/B, W2-AUX1, W3-AUX2, Y, Y2, G, A-L/A, U1, U1, U2, U2, Heat-Off-Cool-Auto-Emergency Heat, Auto-On-Circulate-Follow Schedule, Tri-Lingual Display, 18 - 30 VAC, Battery, Horizontal Mounting, White, 3-1/2 Inch Height x 4-1/2 Inch Width x 7/8 Inch Depth The Prestige® IAQ thermostat is a 2-wire high definition color touch screen thermostat, 7 day programmable and selectable for residential or light commercial use. Controls up to 4-stages of heat and 2-stages of cool in a heat pump system and up to 3-stages of heat and 2-stages of cool in a conventional system. Three sets of universal IAQ contacts to control humidification, dehumidification, and ventilation.

• Control heating, cooling and IAQ equipment with only 2 wires at the thermostat heating, cooling and IAQ equipment wires to the equipment interface module
• Smart schedule - programs in seconds for any lifestyle
• Patented interview based programming and installer setup
• Redlink™ wireless communication
• Increase profit per job by including Redlink™ accessories that provide comfort and convenience
• Light commercial - commercial language (occupied and unoccupied), schedule holidays and custom events, remote setback, economizer and time of day
• Delta T alerts and diagnostics informs customers when their system is not performing as expected with instructions to contact the dealer. Provides a sense of security and greater comfort while generating repeat business
• All Prestige® iaq kits come standard with a return and discharge air temperature sensor to measure delta t
• Alerts and user Interactions log - keeps a searchable history of alerts and setting changes to the thermostat to determine if there is a system malfunction or if the issue was caused by user error. Saves time in troubleshooting and points the technician in the right direction

Application: Heat Pumps
