Lifebreath Ceiling Mount Metro 120ERV-ECM ERV

• 117 CFM @ .3″ w.g / 72% (SRE) at 49 CFM and 0°C (32°F)
• 5” (125 mm) Collars
• Designed for high-rise condos, apartments and townhomes with limited mechanical space
• High efficiency ECM motors
• Low profile, fits in bulkhead and drop ceilings, slim height 9.75”
• Flexible CFM operational range
• Brackets included for easy installation
• No drains required
• Removable motor and electronic assembly for easy maintenance and service
• Convenient hinged door – no screws
• Hardwired, Auto Balance, and Fault Indicator Display configurations available
• Title 24 Compliant. A FID enabled ERV is capable of displaying error codes for certain types of faults which impact operation of the system. FID Version Only
• TOTAL RECOVERY CORE Cross-flow energy recovery core transfers heat and water vapor between two air-streams. Easily removed for cleaning or service.
• MOTORS AND BLOWERS Each airstream has an independant centrifugal blower with ECM motor with multiple fan speed operations.
• FILTERS Washable antimicrobial MERV 6 air filters in exhaust and supply air streams.
• MOUNTING Mounting brackets supplied
• FROST PREVENTION Temperature sensor activated, periodically shuts down supply motor. Drains not required. CASE Twenty gauge prepainted galvanized steel for superior corrosion resistance. Insulated to prevent exterior condensation.
• ELECTRONICS Main control can be wall mounted in a central location. 3 wire 20 gauge (min.) 100 ft. length (max.)

warranty

Units carry a 5 years warranty on the ERV core, and a 5 years replacement parts warranty.
