VanEE 41808 Ceiling Mount Series 70E ECM (ERV)

Part# 41808, VanEE Ceiling Mount Series 70E ECM (ERV) Perfectly integrated into the celing THE SOLUTION FOR HIGH-RISE RESIDENTIAL TOWERS

The ingenious new Bronze Series 70E models meet all of today's building requirements and are easily integrated into the ceiling of each housing unit. A profitable solution at every step in your project!

Outstanding comfort at a very comfortable price

The 70E ECM is equipped with 2 highly efficient ECM motors that provide a significant energy saving of 52% in comparison with the 70E standard model, making it the most energy-efficient ERV of the Bronze series. With a power consumption of 21W at low speed, this new product delivers a ratio of 2.3 CFM/W, making it the perfect solution for in-suite ventilation in energy-efficient multifamily and high rise buildings.

To learn more about wall controls compatible with this unit, please refer to the wall controls specification sheet.

Parts

• Installation Bracket Kit (Set of 2) - SV61240
• Cold Side 5" Metal Port Kit - SV61236
• Adjustable Port Kit - SV61215
• Door Metal Keepers and Latches Kit - SV61218
• Magnet with Bracket Kit - SV61241
• Filter Kit (Set of 2) - SV21029
• Optional MERV7 Filters (Set of 2) - SV21030
• ERV Core - SV61223
• Warm side 5" Metal Port Kit - SV61217

Downloads:

User Guide  Installation Manual  Specification Sheet  Brochure
